Lynx Aurora (n) 8 USB – 8×8 AD/DA Converter with USB Interface & 4 Mic Preamps (24-Bit/192kHz)

OVERVIEW

The Lynx Aurora (n) 8 USB is a mastering-grade AD/DA converter designed for engineers who demand absolute transparency and precision. With 8×8 line-level I/O and integrated USB connectivity, it delivers uncompromising audio performance for recording, mixing, and mastering applications where sonic integrity is critical.

Built around Lynx’s discrete converter architecture, each channel features its own dedicated conversion path, significantly reducing crosstalk while improving dynamic range and clarity. Drawing on technology developed for the flagship Hilo, the Aurora(n) achieves ultra-low distortion and a level of detail that reveals every nuance of your source material.

The integrated LM-PRE4 module adds four (4) high-performance microphone preamps, offering clean gain, low noise, and exceptional headroom for capturing vocals and instruments. Combined with SynchroLock 2™ clocking, onboard microSD recording, and a modular LSlot design for future connectivity upgrades, the Aurora(n) is a long-term investment in uncompromising audio quality.

KEY HIGHLIGHTS

Mastering-Grade AD/DA Conversion

Capture and reproduce audio with exceptional accuracy, depth, and detail – free from unwanted colouration.

Discrete Converter Architecture

Dedicated conversion per channel minimises crosstalk and maximises dynamic range.

Integrated 4-Channel Mic Preamps

High-quality preamps deliver clean, transparent gain for professional recording.

Future-Proof USB Platform

Modular LSlot design allows upgrades to Thunderbolt, Dante, or Pro Tools HD.

Advanced SynchroLock 2™ Clocking

Ultra-low jitter ensures precise timing and superior sonic performance.

FEATURES

• 8×8 line-level AD/DA conversion
• USB interface via LSlot module
• 4 integrated microphone preamps (LM-PRE4)
• 24-bit / 192kHz mastering-grade conversion
• Discrete converter architecture per channel
• Dual high-quality headphone outputs
• SynchroLock 2™ clocking technology
• Internal microSD recording (32 channels)
• Expandable modular design
• Rackmount 1U chassis

TECHNICAL SPECS

Product Type: AD/DA Converter with USB Interface

Format: 1U Rackmount

Conversion: 24-bit / 192kHz

Line I/O: 8 In / 8 Out

Mic Preamps: 4

Monitor I/O: None

AES I/O: None

Connectivity: USB (LSlot modular system)

Headphone Outputs: 2 x Independent

Clocking:

• SynchroLock 2™
• Word Clock: 1 In / 3 Out

Recording:

• Internal microSD (32-channel)

Dimensions:

• Width: 19″
• Depth: 10″
• Height: 1.7″

Weight:

• 3.17 kg (7 lbs)
