KSD A200 MK2 – 3-Way Active Reference Monitor (Cherry) PAIR

OVERVIEW

The A200 MK2 by KSdigital is a compact 3-way reference monitor in Cherry finish that utilises phase-linear FIRTEC™ technology. This advanced technology ensures that all frequencies are radiated simultaneously, resulting in precise and accurate sound reproduction for sound engineers. The A200mk2’s tonal neutrality and timeliness make it suitable for various professional production processes, including recording, mixing, and mastering.

The A200 MK2 features a new mid-high-range unit with a 3″ midrange dome and a 1″ tweeter in an aluminum waveguide. This design creates a homogeneous sound field, allowing for seamless operation in both vertical and horizontal orientations. The 10″ high-performance bass driver delivers powerful low-frequency response above 28Hz. The amplifiers and power supplies are meticulously designed to ensure minimal distortion and exceptional clarity.

KSdigital’s patented FIRTEC system filters produce phase-linear and timely reproduction across the entire frequency range. The MT/HT waveguide not only conceals housing edges but also linearizes the frequency response through digital signal processing. The A200 offers XLR inputs for both analog and digital (24-bit / up to 192 KHz) connections.

The A200 is equipped with high and low shelving filters on the amp, allowing for quick setup and room adjustment. For additional flexibility, the optional KSD RC provides additional internal filters. The monitor also allows direct control of the listening volume, ensuring a lossless digital connection from the master output at full-scale level.

One of the A200’s standout features is its converterless connection (DDD) using three PWM power amplifiers, each delivering 250 W RMS power. This direct digital connection eliminates converter losses, resulting in exceptional resolution and authenticity of the program material.

KEY HIGHLIGHTS

Phase-Linear FIRTEC™ Technology

KSdigital’s patented FIRTEC™ processing ensures frequency and phase linearisation across the entire spectrum. All frequencies arrive simultaneously, resulting in exceptional transient precision, clarity, and accurate stereo imaging.

True 3-Way Precision in a Compact Format

A dedicated 3″ dome midrange, 1″ tweeter in an aluminium waveguide, and a powerful 10″ bass driver work together to deliver controlled, balanced reproduction from deep lows to extended highs – ideal for detailed production work.

Direct Digital Drive (DDD) Amplification

The converterless DDD architecture utilises three PWM amplifiers to minimise signal loss and maximise resolution. The result is outstanding authenticity and dynamic integrity.

Designed for Flexible Studio Integration

With analog (+4 dBV) and AES3 digital inputs (up to 192 kHz), onboard shelving filters, and optional KSD RC remote control, the A200 MK2 adapts easily to professional stereo and multi-channel workflows.

Powerful Low-End Authority

The 10″ high-performance bass chassis delivers tight, controlled low-frequency reproduction down to 28 Hz, providing confidence for mixing and mastering without boom or smear.

FEATURES

• Stereo & Immersive Ready, designed to perform consistently in stereo or multi-channel immersive environments, with stable imaging and accurate spatial translation.
• Patented Phase-Linear FIRTEC™ Processing Technology ensures time-aligned frequency reproduction, delivering exceptional clarity, depth, accuracy, and precise stereo imaging.
• Dedicated 3″ Dome Midrange Driver
• 1″ Silk Tweeter integrated into aluminium waveguide
• 10″ High-Performance Bass Driver
• True 3-Way Architecture for Full-Range Accuracy with dedicated low, mid, and high-frequency drivers providing balanced, natural reproduction across the entire spectrum, making the A200 MK2 equally reliable for tracking, mixing, and mastering.
• Advanced Mid/High Integrated Aluminium Waveguide Design creates a controlled, homogeneous sound field and enables flexible vertical or horizontal placement without compromising tonal balance.
• Converterless Direct Digital Drive (DDD) signal path to the power amplification stage eliminates converter losses, preserving resolution and delivering exceptional authenticity.
• Integrated Room Adjustment Controls with built-in shelving filters allow fast acoustic compensation, while optional remote control access enables deeper room calibration and system integration.
• High-Efficiency Amplification Architecture, thanks to its optimised amplifier and power supply design, ensures clean headroom, minimal distortion, and reliable long-term operation.
• Suitable for vertical or horizontal placement

TECHNICAL SPECS

Type: 3-Way Active Main Reference Monitor (Pair)

High-Frequency Driver: 1″ Fabric/Silk Tweeter

Midrange Driver: 3″ Dome

Low-Frequency Driver: 10″ High-Performance Bass Chassis

Signal Processing: DSP with FIRTEC™ (Patent: 19823110)

Processing Platform: FPGA-Based, 24-bit ADC/DAC

Analog Input: +4 dBV

Digital Input: AES3 (32–192 kHz fs)

Crossover: FIR-Xover

User Controls:

• 6 Parametric EQs
• High & Low Shelving
• Delay
• Gain

Limiter: Integrated

Power Amplifiers: 250 W / 250 W / 150 W

Maximum SPL: 116 dB Continuous / 124 dB Peak (pair)

Frequency Response: 28 Hz – 22 kHz

Dimensions:

• Height — 300 mm
• Width — 420 mm
• Depth — 310 mm

Weight: 17.2 kg (each monitor)

Colour/Finish: Cherry

Accessories (Optional): Table Stand / Wall Mount

Remote Control (Optional): KSD RC – Controls EQ, Volume, Delay and more
