HIGH PASS – The High Pass section is a really easy-to-use sharp filter that cuts all content below one of eight preset frequencies from 30-330 Hz. This filter is very steep and has a special shape that prevents frequencies from thinning out just above the cutoff point. The corner frequency is selected using up/down buttons, and indicated by LEDs that glow softly when the section is bypassed, and brightly when the section is engaged.

HIGH & LOW SHELVING – These two knobs function similarly to the familiar “bass and treble” tone controls found on many consumer audio playback systems; however, these are designed to a much higher performance standard, providing exceptionally smooth and musical boost and cut on the high and low frequencies.

PARAMETRIC EQ – The Lil FrEQ has four sections of fully parametric EQ (LF, Lo Mid, Hi Mid and HF), with each section featuring individual gain, bandwidth (Q) and frequency controls.  It may be the cleanest parametric EQ section ever produced, operating below .0007% THD (Total Harmonic Distortion) even at extremely high audio levels. Try finding those specs anywhere else!

DS (DYNAMIC EQ) – The DS section provides the highest performance, easiest to use, and possibly most natural sounding “De-esser” ever built.  This powerful tool combines tunable filters with a compressor-like circuit that can help contain and control excessive high-frequency content such as sibilants or other sharp transients, especially in the absence of other lower-frequency content.  It can also function as a one-of-a-kind soft knee High Frequency limiter, which is one of the main things responsible for the Lil FrEQ becoming the go-to vocal EQ for engineers everywhere.  It has been used on many acclaimed albums and major live performances all over the world, becoming the “go-to” EQ for key tracks like lead vocals, snares, and bass.  There are now dozens of hit record vocals that were processed through the Lil FrEQ.

“Hey Dave… so I got the box, plugged it in on an Etta James vocal that I was having problems with… and it $#$%^&* rocks.  This is a great box, my friend.  I can see anybody with a DAW wanting to use this thing.  I am using the shelving, DS’ing and transformer out, and I am just thrilled…” – Ed Cherney (Lenny Kravitz, Dave Mathews, Eric Clapton, The Wallflowers, Goo Goo Dolls, Jackson Brown, Bonnie Raitt, Stones, etc.)

“A monster that will destroy the way you think about EQ.” – George Peterson (Mix Magazine)

“…and on the third day, the big guy made the Lil FrEQ… and everybody went f*ck’in freaky.” – Michael Brauer
