Dutch Audio IM1.1S 1u insert machine

$4,149.00

The IM1.1s is a small footprint 1u insert machine with 6 inserts for analog-based studios. The IM1.1s can be used as a 100% transparant passive insert machine, but also has bypassable active circuitry for input gain, mid/side and stepped output gain.

Dutch Audio IM1.1S 1u insert machine

Features

1 stereo input with bypass-able stepped active gain (+/-5.5db) and polarity swap
insert 1 / 2 (passive) with order swap (1>2 or 2>1)
insert 3 / 4 with switchable stereo/MS
insert 5 / 6 (passive) with order swap (5>6 or 6>5)
1 stereo output with stepped active gain (+/-5.5db) and global insert bypass

Specifications

Input and output with goldplated neutrik XLR’s
Inserts with goldplated DB25 analog tascam standard.
Maximum gain passive: >+24dBu
Maximum gain active stages: +24dBu
Noise level passive: >118dB(a)
Noise level active: >116dB(a)
Stereo crosstalk: >110dB(a)
Stereo crosstalk mid/side: ~80dB(a)
THD passive: 0.00042% (AD/DA limitations)
THD active: 0.00045%
Input voltage 100 to 240VAC 50/60HZ. (external PSU)
Power consumption minimum 3 watt maximum 20 watt
Unit size: 1u 19 inch, depth 25cm
Weight: approx 2kg
